ATEN 2-Outlet Eco PDU Power Controller
£209.57
ATEN 2-Outlet Eco PDU Power Controller, Managed, Desk/Wall, Black, 2 AC outlet(s), C13 coupler, C14 coupler
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
Engineered to be an intelligent power distribution solution, the PE4102G Eco PDU Power Controller ships with 2 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize operating costs.
The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level f practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.
The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.
The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level f practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.
The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.
Key Features
- Local/remote control – On/Off/Cycle per outlet
- Power-on sequencing – sets order & delay per port
- Supports Auto Ping & Reboot
- Remote control via TCP/IP & built-in 10/100 Ethernet port
- Works with web-based eco DC software
Specifications
Design
PDU types*
Managed
Rack mounting
Yes
Mounting type
Desk/Wall
Product colour
Black
Ports & interfaces
AC outlets quantity*
2 AC outlet(s)
Power plug
C14 coupler
AC outlet types*
C13 coupler
Ethernet LAN (RJ-45) ports
1
Features
Cable length
3 m
Password protection
Yes
Management features
Supported network protocols
TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3
Power
Nominal input voltage*
100 - 240 V
AC input frequency
50 - 60 Hz
Maximum current*
10 A
Nominal output voltage
100 - 240 V
Load capacity
2400 VA
Certificates
Compliance certificates
Low Voltage Directive (LVD), CE, Electagnetic Compatibility (EMC)
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 60 °C
Operational conditions
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
127.8 mm
Depth
170 mm
Height
44 mm
Weight
980 g
Packaging content
Cables included
AC
Manual
Yes
Packaging data
Package weight
1.27 kg
Package width
95 mm
Package depth
265 mm
Package height
220 mm
Package volume
5550.101932032 cm³
Logistics data
Country of origin
China
Master (outer) case net weight
4.9 kg
Master (outer) case width
232 mm
Master (outer) case length
500 mm
Master (outer) case height
283 mm
Master (outer) case gross weight
6.92 kg
Master (outer) case volume
32819.225200128 cm³
Additional Information
| EAN/UPC | 4711581520578 |
|---|---|
| MPN | PE4102G |
| BRAND | ATEN |
