Neomounts AV50-500BL PTZ/UC camera shelf kit 43-110" - VESA - max 5 kg - universal
£61.36
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The Neomounts AV50-500BL is a universal PTZ/UC camera shelf kit designed for 43" displays and larger, with VESA hole patterns ranging f 200x200 up to 800x600 mm. Built for durability and versatility, the kit supports devices up to 5 kg and can be installed either above or below the display. Both the camera support and the backplate brackets are height-adjustable for maximum flexibility.
Compatible with virtually all* PTZ/UC cameras, the AV50-500BL guarantees broad applicability. The camera mounting allows both width and height variation, while the VESA frame adjusts in four positions (200/400/600/800). The kit is suitable for VESA orientated wall, floor, desk, and ceiling mounts. Despite its versatility, installation is simple and precise thanks to ruler-guided alignment.
* The Neomounts AV50-500BL kit is truly universal, compatible with any PTZ/UC camera that fits within the bracket?s range (see line drawing). In addition, it is specifically designed for the following els:
- Bose Professional VB-S
- Poly Studio R30/X30/X32 and Studio V12
- Logitech Meetup 2 and Rally Camera
- Yealink MeetingBar A30, UVC20/UVC30 Room/UVC34/UVC40 and MeetingEye 400/600
- Maxhub UC S05/S07/S10/S10 Pro/S15
- Predia Connect Camera
For detailed compatibility with specific els or mounting sizes, please refer to the online manual.
Compatible with virtually all* PTZ/UC cameras, the AV50-500BL guarantees broad applicability. The camera mounting allows both width and height variation, while the VESA frame adjusts in four positions (200/400/600/800). The kit is suitable for VESA orientated wall, floor, desk, and ceiling mounts. Despite its versatility, installation is simple and precise thanks to ruler-guided alignment.
* The Neomounts AV50-500BL kit is truly universal, compatible with any PTZ/UC camera that fits within the bracket?s range (see line drawing). In addition, it is specifically designed for the following els:
- Bose Professional VB-S
- Poly Studio R30/X30/X32 and Studio V12
- Logitech Meetup 2 and Rally Camera
- Yealink MeetingBar A30, UVC20/UVC30 Room/UVC34/UVC40 and MeetingEye 400/600
- Maxhub UC S05/S07/S10/S10 Pro/S15
- Predia Connect Camera
For detailed compatibility with specific els or mounting sizes, please refer to the online manual.
Specifications
Features
Product type*
Camera mount
Panel mounting interface
200 x 200,200 x 300,200 x 400,400 x 200,400 x 300,400 x 400,400 x 600,600 x 300,600 x 200,600 x 400,600 x 500,600 x 600,800 x 800,800 x 200,800 x 400,800 x 450,800 x 500,800 x 600
Minimum screen size
109.2 cm (43")
Maximum screen size
2.79 m (110")
Maximum weight capacity
5 kg
Number of displays supported
1
Height adjustment range
0 - 55 mm
Product colour
Black
Housing material
Steel
Minimum VESA mount
200 x 200 mm
Maximum VESA mount
800 x 600 mm
Technical details
Warranty period
5 year(s)
Country of origin
China
Weight & dimensions
Width
900 mm
Depth
158 mm
Weight & dimensions
Height
552 mm
Weight
4.5 kg
Packaging data
Package width
175 mm
Package depth
958 mm
Package height
86 mm
Package weight
5.8 kg
Logistics data
Master (outer) case net weight
13.5 kg
Products per pallet (EU)
48 pc(s)
Master (outer) case width
273 mm
Master (outer) case length
978 mm
Master (outer) case height
195 mm
Master (outer) case gross weight
17.9 kg
Products per master (outer) case
3 pc(s)
Harmonized System (HS) code
7326909890
Additional Information
| EAN/UPC | 8717371449414 |
|---|---|
| MPN | AV50-500BL |
