TP-Link InSight S655I IP security camera Indoor 2560 x 1920 pixels Ceiling/wall
£297.53
TP-Link InSight S655I, IP security camera, Indoor, Wired, 120 dB, CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF, Ceiling/wall
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display e, it functions as four cameras at once, delivering complete coverage and flexible perspectives.
Multiple Display es
Along with the fisheye view, VIGI provides multiple display es, enabling you to focus on every detail exactly as you prefer.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infed lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display e, it functions as four cameras at once, delivering complete coverage and flexible perspectives.
Multiple Display es
Along with the fisheye view, VIGI provides multiple display es, enabling you to focus on every detail exactly as you prefer.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infed lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Key Features
- 5MP Super-High Definition and IR Night Vision
- 360° Coverage without Blind Spots
- Supports Multiple Display es△ and ePTZ
- Supports Ceiling Mount / Wall Mount / Pendant Mount§
- Smart Detection
- Smart Video Enhancement Technology
- Built-In Microphone & Speaker
- IP67 Waterproof and IK10 Vandal-Proof
- H.265+ Compression Technology
- Suitable for Small Indoor Areas like Retail Shops and Offices
Specifications
Performance
Type*
IP security camera
Placement supported*
Indoor
Connectivity technology*
Wired
Wide Dynamic Range (WDR)
Yes
Day/night e
Yes
Infed (IR) cut-off filter
Yes
Dynamic range
120 dB
Certification
CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
Design
Mounting type*
Ceiling/wall
Product colour*
White
Housing material
Metal
Protection features
Weatherproof
International Protection (IP) code
IP67
IK code
IK10
Weatherproof
Yes
Camera
Minimum illumination
0 lx
Lens viewing angle, horizontal
180°
Lens viewing angle, vertical
180°
Lens viewing angle, diagonal
180°
Camera shutter speed
1/3 - 1/10000 s
Number of Privacy masking areas
4
Image sensor
Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Progressive scan
Yes
Sensor type*
CMOS
Panoramic camera
Sensor type (panoramic camera)
CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera)
52 dB
Digital Wide Dynamic Range (DWDR) (panoramic camera)
Yes
Lens system
Detect distance
28.8 m
Observe distance
12 m
Recognize distance
5.7 m
Maximum aperture number
2
Identify distance
2.8 m
Fixed focal length
1.44 mm
Night vision
Night vision*
Yes
Night vision distance
10 m
LED type
IR
Number of illumination LEDs
4
Infra-red wavelength
850 nm
Video
Maximum resolution*
2560 x 1920 pixels
Total megapixels*
5 MP
Video compression formats
H.264, H.264+, H.265, H.265+
Supported graphics resolutions
320 x 240, 640 x 480 (VGA), 1280 x 960, 2048 x 1536 (QXGA), 2560 x 1920
Frame rate
30 fps
Video streaming
Yes
Noise reduction technology
3D noise reduction
Image quality adjustment
Brightness, Contrast, Saturation, Sharpness
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate
64 Kbps to 6 Mbps
Back Light Compensation (BLC)
Yes
Highlight Compensation (HLC)
Yes
Digital Wide Dynamic Range (DWDR)
Yes
Video
Region of Interest (ROI) encoding
Yes
Smart IR
Yes
Audio
Built-in speaker(s)
Yes
Audio system
2-way
Sample rate
8 kHz
Signal-to-Noise Ratio (SNR)
52 dB
Built-in microphone
Yes
Number of microphones
1
Bit rate range
0 - 64 Kbit/s
Network
Ethernet LAN*
Yes
Ethernet interface type
Fast Ethernet
Networking standards
IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Supported network protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi*
No
Bluetooth*
No
Client interoperability
Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
Number of simultaneous live view channels
6 channels
Storage
Built-in HDD*
No
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Security
Password protection
Yes
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Alert notification type
E-mail, Push notification
Privacy protection
Yes
Motion sensor
Yes
Digest ation
Yes
Management features
Web browser
Yes
Cloud-managed*
Yes
Reset button
Yes
Power
Power source type*
DC, PoE
Power consumption (max)
11.76 W
Power consumption (Power over Ethernet (PoE))
12.14 W
DC output voltage
12
Operational conditions
Operating temperature (T-T)
-30 - 60 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Weight & dimensions
Height
56 mm
Diameter
13.2 cm
Weight
440 g
Packaging content
Number of cameras*
1
Technical details
Lens mount interface
M12
Additional Information
| EAN/UPC | 1210002610209 |
|---|---|
| MPN | INSIGHT S655I |
