  • TP-Link InSight S245 Dome IP security camera Outdoor 2688 x 1520 pixels Ceiling

TP-Link InSight S245 Dome IP security camera Outdoor 2688 x 1520 pixels Ceiling

£148.49
TP-Link InSight S245, IP security camera, Outdoor, Wired, 64 m, 120 dB, Ceiling
In stock
  • Immediately available
  • Discreet Packaging
  • Free Shipping

Product Details

Description

People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.△

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.



Key Features

  • 4MP Super-High Definition and 24h Full-Color
  • People & Vehicle Analytics†
  • Human & Vehicle Classification
  • Smart Detection
  • Smart Video Enhancement Technology
  • Active Defense and Two-Way Audio
  • IP67 Waterproof and IK10 Vandal-Proof
  • H.265+ Compression Technology

Specifications

Performance

Type*
IP security camera
Placement supported*
Outdoor
Connectivity technology*
Wired
Maximum operating distance
64 m
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Remote viewing
Yes
Dynamic range
120 dB

Design

Form factor*
Dome
Mounting type*
Ceiling
Product colour*
White
Housing material
Metal
Protection features
Waterproof
International Protection (IP) code
IP67
IK code
IK10
Weatherproof
Yes

Camera

Camera pan control
Yes
Camera tilt control
Yes
Minimum illumination
0 lx
Lens viewing angle, horizontal
110°
Lens viewing angle, vertical
58.1°
Lens viewing angle, diagonal
133.5°
Tilt angle range
0 - 75°
Camera shutter speed
1/3 to 1/10000

Image sensor

Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Progressive scan
Yes
Sensor type*
CMOS

Lens system

Detect distance
64 m
Observe distance
27 m
Recognize distance
13 m
Maximum aperture number
1.6
Identify distance
6 m
Fixed focal length
2.8 mm

Night vision

Night vision*
Yes
LED type
IR/White

Video

Maximum resolution*
2688 x 1520 pixels
Total megapixels*
4 MP
Video compression formats
H.264, H.264+, H.265, H.265+
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video recording
Yes
Image quality adjustment
Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate
Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264
Back Light Compensation (BLC)
Yes
Highlight Compensation (HLC)
Yes
Digital Wide Dynamic Range (DWDR)
Yes

Audio

Built-in speaker(s)
Yes
Audio system
2-way

Audio

Audio input channels
1.0 channels
Audio output channels
1.0 channels
Audio formats supported
G.711 A-law
Sample rate
8 kHz
Built-in microphone
Yes
Number of microphones
1
Bit rate range
0 - 64 Kbit/s

Network

Ethernet LAN*
Yes
Networking standards
IEEE 802.3af, IEEE 802.3at
Supported network protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi*
No
Bluetooth*
No
Live view
Yes

Storage

Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes

Security

Built-in siren
Yes
Password protection
Yes
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Detection distance
64 m
Alert notification type
Push notification
Intelligent Video Surveillance (IVS) system features
Abnormal sound detection, Crossing line, Human detection, Intrusion, Line crossing detection, Moving object, Region entrance detection, Region exiting detection, Scene change, Vehicle detection
Motion sensor
Yes
Mirror
Yes
Human and vehicle targets classification
Yes
Digest authentication
Yes

Management features

Web-based management
Yes
Web browser
Yes
Cloud-managed*
Yes
Reset button
Yes

Power

Power source type*
DC, PoE
Power consumption (Power over Ethernet (PoE))
12.52 W
DC output voltage
12

Operational conditions

Operating temperature (T-T)
-30 - 60 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%

Weight & dimensions

Width
122 mm
Depth
122 mm
Height
89 mm
Weight
620 g

Packaging content

Number of cameras*
1
Manual
Yes

Additional Information

More Information
EAN/UPC 1210002619530
MPN INSIGHT S245(2.8MM)
