Zyxel XMG1930-30HP Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
£1,241.72
Zyxel XMG1930-30HP, Managed, L3, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The XMG1930 series is a family of Multi-Gigabit L2 Smart Managed switches including 2 models, with and without PoE options.
On top of its high-density twenty-four 2.5G ports that serve as a top performance access switch to upgrade from standard gigabit network, the switches also offer four 10G Multi-Gigabit ports to expand network connection to WiFi 6/6E AP or 10G servers along with two additional 10G fiber ports for extensibility and resilience. The PoE model XMG1930-30HP supports both PoE+ and PoE++ with a large power budget of 700 W offering great flexibility to deploy WiFi 6/6E and WiFi 7 wireless access points; while the non-PoE model XMG1930-30 is ideal for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user.
On top of its high-density twenty-four 2.5G ports that serve as a top performance access switch to upgrade from standard gigabit network, the switches also offer four 10G Multi-Gigabit ports to expand network connection to WiFi 6/6E AP or 10G servers along with two additional 10G fiber ports for extensibility and resilience. The PoE model XMG1930-30HP supports both PoE+ and PoE++ with a large power budget of 700 W offering great flexibility to deploy WiFi 6/6E and WiFi 7 wireless access points; while the non-PoE model XMG1930-30 is ideal for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user.
Key Features
- Multi-Gigabit supports with 2.5G and 10G combinations offering flexibility for high density Multi-Gig deployments
- Up to Six 10G uplinks including both copper and fiber options providing extensibility and resilience for networks
- Main ports support up to 2.5G makes the Switch an ideal solution for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user
- Nebula ecosystem offers a unified cloud network experience, from wired, wireless and security gateway
- Smart Managed L2 Switch feature set with L3 static route
- Access and manage the full feature sets included from the first day of purchase through the local web GUI
Specifications
Management features
Switch type*
Managed
Switch layer
L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
Cloud-managed
Yes
Configuring Location Settings (CLI)
Yes
MIB support
✓
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity*
24
Basic switching RJ-45 Ethernet ports type*
2.5G Ethernet (100/1000/2500)
10G Ethernet (copper) ports quantity
4
Installed SFP+ modules quantity*
2
Fiber optic connector
SFP+
Power connector
AC-in jack
Network
Networking standards*
IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
10G support*
Yes
Policy-based routing
Yes
Flow control support
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s
VLAN support
Yes
Number of VLANs
4000
Data transmission
Switching capacity*
240 Gbit/s
Forwarding rate
178.5 Mpps
MAC address table*
16000 entries
Static route
Yes
Jumbo frames support
Yes
Jumbo frames
12000
Security
DHCP features
DHCP client, DHCPv6 relay
Access Control List (ACL)
Yes
IGMP snooping
Yes
MAC address filtering
Yes
SSH/SSL support
Yes
Loop protection
Yes
Multicast features
Multicast support
Yes
Protocols
GARP VLAN Registration Protocol (GVRP)
Yes
Design
Rack mounting*
Yes
Form factor
1U
Product colour
Black
Reset button
Yes
LED indicators
Yes
Performance
Mean time between failures (MTBF)
587922.31 h
Power
Power source*
AC
Power supply included*
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
864.1 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
Yes
Power over Ethernet (PoE) ports quantity
28
Power over Ethernet plus (PoE+) ports quantity
20
Total Power over Ethernet (PoE) budget
700 W
Operational conditions
Operating temperature (T-T)
-20 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Heat dissipation
864.1 BTU/h
Weight & dimensions
Width
441 mm
Depth
330 mm
Height
44 mm
Weight
4.85 kg
Packaging content
Cables included
AC
Rack mount kit
Yes
Additional Information
| EAN/UPC | 4718937622078 |
|---|---|
| MPN | XMG1930-30HP-ZZ0101F |
