TP-Link INSIGHT S485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling

£202.82
TP-Link INSIGHT S485, IP security camera, Outdoor, Wired, 85 m, 120 dB, Ceiling
In stock
  • Immediately available
  • Discreet Packaging
  • Free Shipping

Product Details

Description

People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Human & Vehicle Classification
Distinguish humans and vehicles f other objects and receive more accurate event notifications.

True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.△

Smart IR: Smart IR dynamically adjusts infed lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Key Features

  • 4K (8MP) Ultra HD and 24h Full-Color
  • People & Vehicle Analytics§
  • Human & Vehicle Classification
  • Smart Detection
  • Smart Video Enhancement Technology
  • Active Defense and Two-Way Audio
  • IP67 Waterproof
  • H.265+ Compression Technology
  • 12V DC/PoE

Specifications

Performance

Type*
IP security camera
Placement supported*
Outdoor
Connectivity technology*
Wired
Maximum operating distance
85 m
Wide Dynamic Range (WDR)
Yes
Day/night e
Yes
Infed (IR) cut-off filter
Yes
Remote viewing
Yes
Dynamic range
120 dB

Design

Form factor*
Turret
Mounting type*
Ceiling
Product colour*
White
Housing material
Metal
Protection features
Waterproof
International Protection (IP) code
IP67
Weatherproof
Yes

Camera

Lens viewing angle, horizontal
111.4°
Lens viewing angle, vertical
58.8°
Lens viewing angle, diagonal
134°
Tilt angle range
0 - 90°
Camera shutter speed
1/3 to 1/10000

Image sensor

Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Progressive scan
Yes
Sensor type*
CMOS

Lens system

Detect distance
85 m
Observe distance
35 m
Recognize distance
17 m
Fixed focus
Yes
Maximum aperture number
1.6
Identify distance
8 m
Fixed focal length
2.8 mm

Night vision

Night vision*
Yes
LED type
IR/White

Video

Maximum resolution*
3840 x 2160 pixels
Total megapixels*
8 MP
Video compression formats
H.264, H.264+, H.265, H.265+
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 3840 x 2160
Video recording
Yes
Image quality adjustment
Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate
Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
Back Light Compensation (BLC)
Yes
Highlight Compensation (HLC)
Yes
Digital Wide Dynamic Range (DWDR)
Yes

Audio

Built-in speaker(s)
Yes
Audio system
2-way
Audio input channels
1.0 channels
Audio output channels
1.0 channels
Audio formats supported
G.711 A-law

Audio

Sample rate
8 kHz
Built-in microphone
Yes
Number of microphones
1
Bit rate range
0 - 64 Kbit/s

Network

Ethernet LAN*
Yes
Networking standards
IEEE 802.3af, IEEE 802.3at
Supported network protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi*
No
Bluetooth*
No
Live view
Yes

Storage

Compatible memory cards
MicroSD (TransFlash)
Maximum memory card size
512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes

Security

Built-in siren
Yes
Password protection
Yes
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Alert notification type
Push notification
Motion sensor
Yes
Mirror
Yes

Management features

Web-based management
Yes
Web browser
Yes
Cloud-managed*
Yes
Reset button
Yes

Power

Power source type*
DC, PoE
Power consumption (max)
11.5 W
Power consumption (Power over Ethernet (PoE))
12.5 W
DC output voltage
12

Operational conditions

Operating temperature (T-T)
-30 - 60 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%

Weight & dimensions

Width
111 mm
Height
83.7 mm
Length
111 mm
Weight
480 g

Packaging data

Package type
Box

Packaging content

Number of cameras*
1
Mounting kit
Yes
Screws included
Yes
Drilling template included
Yes
Manual
Yes

Additional Information

More Information
EAN/UPC 1210002605663
MPN INSIGHT S485(2.8MM)
BRAND TP-LINK
