Networking
D-Link 24-port 10GBASE-T + 4-port 10/25G SFP28 Smart Managed Switch
£2,190.49
D-Link 24-port 10GBASE-T + 4-port 10/25G SFP28 Smart Managed Switch, Managed, L2/L3, 10G Ethernet (100/1000/10000), Rack mounting, 1U
Out of stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The DXS-1210-28T/28S 10 Gigabit Ethernet Smart Managed Switches are a cost-effective 10
Gigabit switches capable of servicing a range of network needs in any business environment.
The DXS-1210-28T is equipped with 4 x 10/25G SFP28 ports, enabling this series to serve as
either an aggregation/access switch in large enterprise environments or deployed at the
core of an SMB network. With high performance and low latency, these 10G smart-managed
switches fulfil the needs of virtualisation, cloud services, and server-to-server applications.
The DXS-1210-28T/28S comes with a complete line-up of L2 features, including port mirroring,
Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). At the same time,
inter-VLAN static routing helps by reducing the pressure of routers and backbone networks,
improving overall network efficiency. The free D-Link Network Assistant utility allows multiple
D-Link devices within the same L2 network to be discovered and managed. These switches also
provide management through the multi-lingual web UI, a full command-line interface (CLI)
through Telnet, a console port, as well as D-View 7 Network Management System.
Gigabit switches capable of servicing a range of network needs in any business environment.
The DXS-1210-28T is equipped with 4 x 10/25G SFP28 ports, enabling this series to serve as
either an aggregation/access switch in large enterprise environments or deployed at the
core of an SMB network. With high performance and low latency, these 10G smart-managed
switches fulfil the needs of virtualisation, cloud services, and server-to-server applications.
The DXS-1210-28T/28S comes with a complete line-up of L2 features, including port mirroring,
Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). At the same time,
inter-VLAN static routing helps by reducing the pressure of routers and backbone networks,
improving overall network efficiency. The free D-Link Network Assistant utility allows multiple
D-Link devices within the same L2 network to be discovered and managed. These switches also
provide management through the multi-lingual web UI, a full command-line interface (CLI)
through Telnet, a console port, as well as D-View 7 Network Management System.
Key Features
- Access Control List
- IP-MAC-Port Binding
- Clientless MAC/Web Access Control
- D-Link Safeguard Engine
- Port Security
- ARP Spoofing Prevention
Features
![](alt="")
10 Gigabit Ethernet Smart Managed Switches
- 10GbE bandwidth connections
- 25GbE SFP28 ports1 (DXS-1210-28T only)
- Layer 2 management and security, with Layer 3 Lite features
- Industry standard full CLI, web-based GUI, console port
- Static Routing and MSTP
10/25-Gigabit ports
10/25GbE connections for low-latency, to easily meet high-bandwidth demands, and device flexibility across the network.Web-based GUI
Intuitive remote management interface makes setups and configurations easier, and reduces switch deployment times.Layer 2 Features
Includes port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP).Layer 3 Lite Features
Such as IP Interfaces, ARP, IPv6 Neighbor Discovery (ND), Default Routing and Static Routing.Energy Saving Technology
Powers down any unused ports, and includes LED shut-off, port shut-off, port standby.Quality of Service (QoS)
Rich QoS controls, including bandwidth control, and Auto Surveillance VLAN.Network Security
D-Link’s Safeguard Engine™ helps protect against traffic flooding f malicious attacks.Affordable 10/25G capabilities, for a reliable high-speed network.
Add 10/25-Gigabit Ethernet connectivity to your network with these cost-effective switches. Designed to work as the network core for Small to Medium Businesses (SMBs) or as an aggregation switch in a larger Enterprise.
Extensive Layer 2 & Layer 3 Lite features.
The DXS-1210 series includes layer 2 features such as port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). They also support IP interfaces, ARP, IPv6 Neighbor Discovery (ND), default routing, IPv4/IPv6 static routing, IGMP and MLD Snooping, auto voice and surveillance VLAN, LLDP and LLDP-MED.Improved intranet performance
Inter-VLAN routing allows traffic to be routed between VLANs without passing through the router, reducing the load on the router as well as the backbone networks.
Security and QoS controls for priorities
Security controls for protection of the network, and QoS ensures essential traffic reaches its destination.
Seamless integration.
The DXS-1210 Series comes with both RJ45 and SFP+ ports capable of connecting to Cat. 6 and fibre for 10G Ethernet. Additionally, the DXS-1210-28T comes with 4 x 10/25G SFP28 ports. This means the DXS-1210 series can provide a flexible solution for upstream or downstream server connections, making network deployment easier.Security with every port.
The innovative D-Link Safeguard Engine protects the switches against traffic flooding caused by malicious attacks and increases overall network reliability.These switches also feature Address Resolution Protocol (ARP) spoofing prevention which further protects the network f cyber attacks. They also use packet control ACLs to block invalid packets that contain ARP messages.
The Access Control List (ACL) helps protect the internal IT network through permission-based network access.
The DHCP server screen feature filters DHCP replies on unauthorised ports to prevent them f being assigned an IP address.
And support for 802.1X port-based and host-based ation allows the network to be ated through external RADIUS servers.
QoS and Bandwidth Control for network priorities.
The DXS-1210 Series supports Auto Surveillance VLAN (ASV) and Auto Voice VLAN, to make faster VoIP and video surveillance deployments.
Auto Surveillance VLAN
Automatically detects and assigns video surveillance traffic to a high-priority VLAN by creating distinct broadcast domains to guarantee that quality -time video is transferred.
Auto Voice VLAN
Enhances the VoIP service by automatically placing voice traffic f IP phones to a designated VLAN. With a prioritised and segmented VLAN, this feature guarantees quality and security of VoIP traffic.
As a result, the voice and video packets take precedence over other packets. And with bandwidth control, more bandwidth can be reserved for important functions.
Energy efficient, without sacrifices.
With D-Link Green technology included, this series saves power without any loss of operational performance or functionality.
Auto-adjusting fans with heat sensors
Built-in smart fans with internal heat sensors monitor and detect temperature changes and react by utilising different fan speeds to keep systems at optimal temperature.Sleep e
Link status drastically reduces power consumption by automatically putting ports without a link into sleep e.Advanced Chipset
Utilises silicon technology to make energy use more efficient.Free Next-Business-Day Service
Enjoy our free Next Business Day service, as standard, to replace faulty equipment quickly.
Specifications
Management features
Switch type*
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity*
24
Basic switching RJ-45 Ethernet ports type*
10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity
24
Console port
RJ-45
SFP28 ports quantity
4
Network
Networking standards*
IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Cable types supported
Cat6, Cat6a, Cat7
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Number of VLANs
4094
Data transmission
Switching capacity*
680 Gbit/s
Forwarding rate
505.92 Mpps
MAC address table*
32000 entries
Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
9000
Security
Access Control List (ACL)
Yes
Access Control List (ACL) rules
256
IGMP snooping
Yes
Protocols
Management protocols
SNMP v1/v2c/v3
GARP VLAN Registration Protocol (GVRP)
Yes
Design
Rack mounting*
Yes
Form factor
1U
Product colour
Black
LED indicators
Activity, Link, Speed
Number of fans
2 fan(s)
Performance
Noise level
51.9 dB
Power
AC input voltage
100 - 240 V
Power consumption (max)
87.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
No
Operational conditions
Operating temperature (T-T)
-5 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
441 mm
Depth
209.5 mm
Height
44 mm
Weight
3.07 kg
Certificates
Certification
CE Class A
FCC Class A
VCCI Class A
IC
BSMI
Logistics data
Harmonized System (HS) code
85176990
Additional Information
| EAN/UPC | 790069456800 |
|---|---|
| MPN | DXS-1210-28T |
| BRAND | D-Link |
