Viewsonic VB-WIFI-004 network card WLAN
£38.93
Viewsonic VB-WIFI-004, Wired, USB, WLAN, Wi-Fi 6 (802.11ax), Black
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The ViewSonic VB-WIFI-004 Wireless Products' target='_self' >wireless module delivers fast internet connection for the ViewBoard®32-2 series. It supports dual-frequency 2.4GHz and 5GHz bandwidth, along with the 802.11AX standard.
Faster Connections
An optional Wi-Fi module for the ViewBoards 32-2 Series facilitates smooth lesson flow and drives a more interactive discussion in the classroom.
Dual Band Wireless Support
Supported by both 2.4 GHz and 5 GHz dual-band wireless transmission, teachers can smoothly stream multimedia content such as videos and images without any delays and create higher student engagement. The 2.4 GHz connection travels farther at lower speeds, while 5 GHz frequencies provide faster speeds at a shorter range.
Faster Connections
An optional Wi-Fi module for the ViewBoards 32-2 Series facilitates smooth lesson flow and drives a more interactive discussion in the classroom.
Dual Band Wireless Support
Supported by both 2.4 GHz and 5 GHz dual-band wireless transmission, teachers can smoothly stream multimedia content such as videos and images without any delays and create higher student engagement. The 2.4 GHz connection travels farther at lower speeds, while 5 GHz frequencies provide faster speeds at a shorter range.
Specifications
Ports & interfaces
Connectivity technology*
Wired
Host interface*
USB
Interface*
WLAN
USB ports quantity
1
Network
Wi-Fi
Yes
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Design
Component for*
Interactive whiteboard
Product colour
Black
Antenna
Yes
Antenna design
Internal
Certification
CE (EMC-safety), CE-RED, WPC, LVD, RCM, FCC ID, IC ID
Power
Power consumption (typical)
5 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
208 mm
Depth
30 mm
Height
20 mm
Weight
85 g
Packaging data
Package width
212 mm
Package depth
35 mm
Package height
25 mm
Package weight
102 g
Additional Information
| EAN/UPC | 766907018974 |
|---|---|
| MPN | VB-WIFI-004 |
| BRAND | VIEWSONIC |
