Allied Telesis AT-IE048-480-20 uninterruptible power supply (UPS) 480 W
£250.36
Allied Telesis AT-IE048-480-20, 480 W, 90 V, 350 V, 50/60 Hz, 48 V, 15 A
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The ruggedized IE048-480 industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for Smart Cities (e.g. Surveillance & Security), Industrial Ethernet, Transportation or any application requiring systems that function in harsh environment with extended operating temperature.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics f power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics f power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Key Features
- ۼ Electagnetic immunity for industrial environments
- ۼ High efficiency
- ۼ Active PFC
- ۼ Stable output power with 150% peak current capability
- ۼ Wide input voltage range
- ۼ Protections: peak-current, over-current and over-temperature
- ۼ Remote ON/OFF
- ۼ Output power confirmation relay (DC_OK)
- ۼ Extended operating temperature range
- ۼ Air convention cooling
- ۼ Metal case
- ۼ DIN rail mount
Specifications
Features
Output power*
480 W
Input operation voltage (min)*
90 V
Input operation voltage (max)*
350 V
Input frequency*
50/60 Hz
Output operation voltage (max)
48 V
Maximum current
15 A
Efficiency
94%
Power factor
0.98
Power protection features
Over current, Over voltage, Overheating
Design
Form factor*
Tower
Housing material
Metal
Cooling type
Active
Product colour*
White
LED indicators
Alarm, Status
Operational conditions
Operating temperature (T-T)
-20 - 70 °C
Operational conditions
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
20 - 90%
Storage relative humidity (H-H)
20 - 90%
Certificates
Compliance certificates
RoHS, WEEE
Weight & dimensions
Width
70 mm
Depth
117 mm
Height
124 mm
Weight
1.2 kg
Logistics data
Export Control Classification Number (ECCN)
5A992C
Harmonized System (HS) code
8504.40.8500
Other features
Nominal output voltage
48 V
Nominal input voltage
90 - 264; 98 - 350 V
Additional Information
| EAN/UPC | 767035216478 |
|---|---|
| MPN | AT-IE048-480-20 |
| BRAND | ALLIED TELESIS |
