APC Easy Rack PDU, Basic, 1U, 1 Phase, 3.7kW, 230V, 16A, 8 x C13 outlets, IEC60320 C20 inlet

£86.30
APC Easy Rack PDU, Basic, 1U, 1 Phase, 3.7kW, 230V, 16A, 8 x C13 outlets, IEC60320 C20 inlet, Basic, 1U, Single-phase, Horizontal, Aluminium, Black
In stock
  • Immediately available
  • Discreet Packaging
  • Free Shipping

Product Details

Description

APC Easy Basic Rack PDU EPDU1016B is Easy-to-install and easy-to-use PDU, making rack power distribution easy. This offers more than a power strip for server rack and network rack solutions. This is horizontal rack mountable PDU in ultra light weight upto 50% weight reduction with Aluminum housing. EPDU1016B has IEC-320 C20 200-240V type inlet and eight IEC C13 type outlet sockets. This can operate from -5° to +45°C temperation range and comes with 1 year of standard warranty. The packaging includes cable, installation guide, user manual and rack mounting brackets for quick and easy mounting inside the rack. Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 17.3kW using a single branch whip. Saves time and money during installation by using one branch whip and standard connections.

Specifications

Design

PDU types*
Basic
Type
Single-phase
Rack capacity*
1U
Mounting
Horizontal
Housing material
Aluminium
Product colour
Black
On/off switch
No

Ports & interfaces

AC outlets quantity*
8 AC outlet(s)
Power plug
C20 coupler
AC outlet types*
C13 coupler

Features

Daisy chain
No
Cable length
2.5 m

Power

Nominal input voltage*
200/208/230 V
AC input frequency
50 - 60 Hz
Maximum current*
16 A
Nominal output voltage
208/230 V
Load capacity
3680 VA
Maximum input current per phase
16 A
Maximum power
3680 W

Certificates

Compliance certificates
RoHS
Certification
CE, TUV

Operational conditions

Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-25 - 65 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 15000 m

Weight & dimensions

Width
482 mm
Depth
44 mm
Height
44 mm
Weight
580 g

Packaging content

Manual
Yes

Packaging data

Package weight
1.18 kg
Package width
560 mm
Package depth
80 mm
Package height
150 mm

Additional Information

More Information
EAN/UPC 731304404996
MPN EPDU1016B
BRAND APC
