iiyama 65" Open Frame PCAP interactive large format display with 50pt touch capability, IPS panel te
£3,564.00
Out of stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Description
The 4K UHD (3840x2160) Open Frame TF6539UHSC-B1AG with Touch-Through-Glass function guarantees a seamless and accurate touch response for true kiosk integration or interactive behind-glass-retail applications. The IPS panel technology offers exceptional colour performance and wide viewing angles, making it a perfect solution for interactive shop windows, education, kiosks and in-store communications. Featuring a metal housing with 60950-1 ball-drop proof, scratch-resistant and edge-to-edge glass, this display can be installed in the most demanding environments for an 24/7 usage and in different set-ups as a result of its Open Frame side mounting holes. For ease of integration, the TF6539UHSC-B1AG can be equipped with optional external mounting brackets ( OMK4-2 ) making it an ideal solution for kiosk integrators and interactive multimedia.
Reasons To Buy
IPS Technology
Touch through-glass
Touch technology - Capacitive
AG Coating
24/7
Specifications
Display
Panel type
IPS
LED backlight
Yes
Display diagonal*
165.1 cm (65")
Display technology*
LCD
Display resolution*
3840 x 2160 pixels
Display brightness*
500 cd/m²
HD type*
4K Ultra HD
Touchscreen*
Yes
Number of simultaneous touchpoints
50
Response time
8 ms
Contrast ratio (typical)
1100:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Display number of colours
16.78 million colours
Ports & interfaces
HDMI ports quantity*
2
HDMI version
1.4/2.0
DisplayPorts quantity*
1
DisplayPort version
1.2
Ethernet LAN (RJ-45) ports
1
Audio
Built-in speaker(s)*
Yes
Number of built-in speakers
2
Design
Product design*
Interactive flat panel
Product colour*
Black
VESA mounting*
Yes
Panel mounting interface
600 x 400 mm
Performance
Purpose*
Commercial
HDCP
Yes
Performance
Mean time between failures (MTBF)
50000 h
Power
Power consumption (typical)*
175 W
Power consumption (standby)*
0.5 W
Power consumption (off)
0.5 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Energy efficiency scale
A to G
Weight & dimensions
Width
1503.5 mm
Depth
67 mm
Height
880.5 mm
Weight
56 kg
Packaging data
Package width
1670 mm
Package depth
310 mm
Package height
1020 mm
Package weight
65 kg
Packaging content
Cables included
AC, DisplayPort, HDMI, USB
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Certificates
Certification
CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, UKCA
Technical details
Sustainability certificates
ErP
Compliance certificates
CE, REACH, RoHS, WEEE
Other features
Quick start guide
Yes
Additional Information
| EAN/UPC | 4948570118083 |
|---|---|
| MPN | TF6539UHSC-B1AG |
| BRAND | Iiyama |
