TP-Link Omada DR3220v-4G wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
£304.36
In stock
- Immediately available
- Discreet Packaging
- Free Shipping
Product Details
Key Features
- AX3000 WiFi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*1*4
- VDSL2 35b: Supports 350Mbps DSL Access*2
- VDSL2/ADSL2+/ADSL2/ADSL Compatibility
- Centralized Cloud Management
- IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN
- Load Balancing Between DSL and Ethernet WAN
- Omada Mesh Technology*3
- 3 × RJ11 Ports (2 × FXS, 1 × DSL) & 5 × RJ45 Gigabit Ports & 2 × USB 3.0 Ports
- Desktop/Wall Mounting
- 8.9 × 5.2 × 1.4 in (226 × 131.2 × 35 mm)
Specifications
WAN connection
Ethernet WAN*
Yes
DSL WAN*
Yes
SIM card slot*
No
3G/4G USB em compatibility*
Yes
WAN connection type
RJ-45
Wireless LAN features
Wi-Fi band*
Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)*
2402 Mbit/s
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)
574 Mbit/s
WLAN data transfer rate (second band)
2402 Mbit/s
Network
Ethernet LAN*
Yes
Ethernet LAN interface type*
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Port triggering
Yes
Load balancing system
Yes
Dynamic DNS (DDNS)
Yes
Policy-based routing
Yes
Static route
Yes
Built-in FTP server
Yes
VPN support
IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN
DSL features
ADSL
Yes
ADSL2
Yes
ADSL2+
Yes
VDSL2
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports*
4
USB port*
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
RJ-11 ports quantity
3
DC-in jack
Yes
Management features
Web-based management
Yes
Quality of Service (QoS) support
Yes
Reset button
Yes
MU-MIMO technology
Yes
Security
Security algorithms
WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Guest access
Yes
Security
Access Control List (ACL)
Yes
URL filtering
Yes
System event log
Yes
DMZ support
Yes
Network address translation (NAT)
Yes
Protocols
DHCP client
Yes
DHCP server
Yes
Universal Plug and Play (UPnP)
Yes
Voice codecs
G.711a, G.711ulaw, G.722, G.726, G.729ab
Design
Product colour
Black
Wall mountable
Yes
Indication light
Yes
LED indicators
DSL, LAN, USB, WLAN
Product type*
Tabletop router
Packaging content
Cables included
LAN (RJ-45), Phone
AC adapter included
Yes
Antenna included
Yes
Antenna
Antenna design*
External
Antenna gain level (max)
4.5 dBi
Antennas quantity
3
Detachable antenna(s)
Yes
Power
Power source type*
AC
Output voltage
12 V
Output current
3.3 A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Weight & dimensions
Width
226 mm
Depth
131 mm
Height
35 mm
Packaging data
Package type
Box
Number of products included
1 pc(s)
Additional Information
| EAN/UPC | 1210002608411 |
|---|---|
| MPN | DR3220V-4G |
